Description
| TANK CAPACITY | 120 gal / 16 ft³ |
| PRESSURE | 200 PSI |
| CONFIGURATION | Vertical |
| MOUNT | Base Ring |
| DIMENSIONS (TOP PLATE) | 24×67 IN (30×45 IN) |
| WEIGHT (TOP PLATE) | 275 LB (432 LB) |
Compressed air and gas storage is key to any system – storing energy for later use. Samuel manufactures high quality, ASME certified receivers for reliable air storage, perfect for pairing with a base mounted air compressor. This model of receiver tank has 120 gallons of capacity, is rated for 200PSI, and is available with or without a top mounting plate.
- Vertical storage tank with base ring for compressed air and gas systems
- Available with optional 15″x39″ top plate
- Steel construction with standard primer exterior – universal water based alkyd enamel
- Constructed in accordance with ASME standards
- Tank Kit includes: (1) Safety Relief Valve, (1) Gauge, (1) Ball Valve
- Recommended – install an Automatic Drain Valve
INTERIOR/EXTERIOR COATING OPTIONS AVAILABLE:
- INTERIOR: Powder Coat, or Epoxy
- EXTERIOR: Powder Coat, or Enamel
- Additional cost & lead time, contact us for quote
DOWNLOAD SPEC SHEETS HERE: A10047, A10049
