Description
| TANK CAPACITY | 400 gal / 53.5 ft³ |
| PRESSURE | 165 PSI or 200 PSI |
| CONFIGURATION | Vertical |
| MOUNT | Base Ring |
| DIMENSIONS | 36×93 IN |
| WEIGHT | 717 LB or 815 LB |
Compressed air and gas storage is key to any system – storing energy for later use. Samuel manufactures high quality, ASME certified receivers for reliable air storage, perfect for pairing with a base mounted air compressor. This model of receiver tank has 400 gallons of capacity, and is rated for either 165PSI or 200PSI.
- Vertical storage tank with base ring for compressed air and gas systems
- Steel construction with standard primer exterior – universal water based alkyd enamel
- Constructed in accordance with ASME standards
- Tank Kit includes: (1) Safety Relief Valve, (1) Gauge, (1) Ball Valve
- Recommended – install an Automatic Drain Valve
INTERIOR/EXTERIOR COATING OPTIONS AVAILABLE:
- INTERIOR: Powder Coat, Epoxy, or FDA/NSF Lining
- EXTERIOR: Powder Coat, or Enamel
- Additional cost & lead time, contact us for quote
DOWNLOAD SPEC SHEETS HERE: A10055, A10056X
